13-21NM Long Range Marine Lantern <br>(SL-300-1D5)

Stand Alone Marine Lanterns

13-21NM Long Range Marine Lantern <br>(SL-300-1D5)
13-21NM Long Range Marine Lantern <br>(SL-300-1D5)13-21NM Long Range Marine Lantern <br>(SL-300-1D5)13-21NM Long Range Marine Lantern <br>(SL-300-1D5)13-21NM Long Range Marine Lantern <br>(SL-300-1D5)13-21NM Long Range Marine Lantern <br>(SL-300-1D5)

13-21NM Long Range Marine Lantern
(SL-300-1D5)

The SL-300-1D5 series are 13 to 21NM long-range marine lanterns with 1.5 degree vertical distribution, suitable for a range of applications.

The SL-300-1D5 series offers multiple intensity adjustments to over 90,000cd luminous intensity in a single tier (over 180,000 in a 2-tier configuration).

The small form factor provides minimal wind loading and convenient handling – delivering significant advantages over traditional large lens stack assemblies.

These high intensity lanterns are programmed using Sealite’s advanced PC or IR Programming tools. GPS synchronisation and GSM monitoring and control are offered as options on this model.

These long range lanterns produce a class-leading intensity to power ratio, making them highly efficient and suitable for solar power solutions.

  • Over 90,000cd luminous intensity white – single tier
  • Over 180,000cd luminous intensity white – two tier
  • Compact lantern up to 21NM visible range
  • PC or IR Programmer for setup, diagnostics & testing
  • Internal or external photocell options
  • User configurable day/night lux levels
  • Advanced remote monitoring features
  • Wide operating voltage range 20 58VDC
  • Internal data-logging for long term retention of key operational parameters & alarm conditions
  • General purpose inputs (two) & outputs (two)
  • GPS Synchronisation
  • Integrated to external Type 1 or Type 3 AIS
  • GSM Monitoring & Control System
  • RS232/422/485 Port
  • General purpose inputs (2) & outputs (2)
  • Variety of solar/battery configurations
  • Bird deterrent spikes
  • Serial programming cable
  • Immunity: EN 61000-6-1: 2007 (IEC61000-6-1: 2005)
  • Emission: EN 61000-6-4: 2007 (IEC 61000-6-4: 2006) + A1: 2001
  • FCC Part 15 Rules: IFCC Part 15 Subpart B
  • IALA: Signal colours compliant to IALA E-200-1
  • Quality Assurance: ISO 9001:2015
Description

The SL-300-1D5 series are 13 to 21NM long-range marine lanterns with 1.5 degree vertical distribution, suitable for a range of applications.

The SL-300-1D5 series offers multiple intensity adjustments to over 90,000cd luminous intensity in a single tier (over 180,000 in a 2-tier configuration).

The small form factor provides minimal wind loading and convenient handling – delivering significant advantages over traditional large lens stack assemblies.

These high intensity lanterns are programmed using Sealite’s advanced PC or IR Programming tools. GPS synchronisation and GSM monitoring and control are offered as options on this model.

These long range lanterns produce a class-leading intensity to power ratio, making them highly efficient and suitable for solar power solutions.

Features
  • Over 90,000cd luminous intensity white – single tier
  • Over 180,000cd luminous intensity white – two tier
  • Compact lantern up to 21NM visible range
  • PC or IR Programmer for setup, diagnostics & testing
  • Internal or external photocell options
  • User configurable day/night lux levels
  • Advanced remote monitoring features
  • Wide operating voltage range 20 58VDC
  • Internal data-logging for long term retention of key operational parameters & alarm conditions
  • General purpose inputs (two) & outputs (two)
Options
  • GPS Synchronisation
  • Integrated to external Type 1 or Type 3 AIS
  • GSM Monitoring & Control System
  • RS232/422/485 Port
  • General purpose inputs (2) & outputs (2)
  • Variety of solar/battery configurations
  • Bird deterrent spikes
  • Serial programming cable
Certifications
  • Immunity: EN 61000-6-1: 2007 (IEC61000-6-1: 2005)
  • Emission: EN 61000-6-4: 2007 (IEC 61000-6-4: 2006) + A1: 2001
  • FCC Part 15 Rules: IFCC Part 15 Subpart B
  • IALA: Signal colours compliant to IALA E-200-1
  • Quality Assurance: ISO 9001:2015
Downloads
FacebookTwitterLinkedin
Product Code: SL-3001D5-1, SL300-1D5-2
